Protape®

Description

Aeroflex® Protape® EPDM Seam Tape is a zero-perm, 24-mil thick EPDM rubber tape designed for vapor-sealing glued seams of AEROFLEX® EPDM closed-cell elastomeric insulation. This durable, self-extinguishing tape provides a reliable vapor barrier to prevent water vapor ingress, minimizing the risk of corrosion under insulation (CUI). Protape® is available in black and white/gray color options for use in HVAC, refrigeration, VRF, chilled water, and hot/cold-water piping applications.

Specifications

Composition: EPDM-based rubber tape
Thickness: 24 mils (± 4 mils)
Service Temperature Range: -70°F to 257°F (-57°C to 125°C)
Water Vapor Permeability: 0.00 perm-inch (ASTM E96)
UV Resistance: Pass (ASTM G7)
Ozone Resistance: No cracking (ASTM D1171)
Flammability:
- Flame Spread Index: ≤25; Smoke Developed Index: ≤50 (ASTM E84, UL723)
- Self-extinguishing (ASTM D635)
VOC Emissions: < 0.5 mg/m³ (CDPH Standard Method v1.2)

Features

Zero-Perm Vapor Barrier: Effectively prevents moisture ingress to protect against condensation and CUI.
Durable and Flexible: Designed to expand and contract with AEROFLEX® insulation, offering 50% elongation.
Safe for Multiple Applications: Suitable for both interior and exterior environments with optional UV protection for extended outdoor use.
Non-Corrosive: Safe for use on copper and stainless-steel piping without causing corrosion.

Certifications & Compliance

Building Code Compliance:
- ANSI/ASHRAE/ICC/USGBC/IES Standard 189.1 and ANSI/ASHRAE/IES Standard 90.1
- California Title 24, LEED® and IECC® compliant
Environmental Certifications:
- GREENGUARD Gold Certified
- EPA TSCA, REACH, and RoHS compliant for health and safety standards
