AEROFLEX®-EP FM Approved

Description

Aeroflex®-EP EPDM Pipe & Duct Insulation is a closed-cell elastomeric foam insulation solution designed for HVAC, VRF, chilled water, refrigeration, and hot/cold water piping applications. It provides exceptional thermal performance, moisture control, and environmental durability, with superior UV and ozone resistance. This FM-approved insulation, available in tubes, sheets, and rolls, is engineered to reduce condensation and conserve energy while protecting pipes and ducts.

Specifications

Thermal Conductivity (K):
- 50°F (10°C): 0.257 (0.037 W/m•K)
- 75°F (24°C): 0.266 (0.038 W/m•K)
- 100°F (38°C): 0.276 (0.040 W/m•K)
- 150°F (66°C): 0.290 (0.042 W/m•K)
Service Temperature: -70°F to 257°F (-57°C to 125°C)
Water Vapor Permeability: Max < 0.10 perm-inch (ASTM E96)
Flammability:
- Passes FM 4924, ASTM E84
- UL94 V-0 rating (2″ thickness or less)
VOC Content: Ultra-low, < 1% PVC
Environmental Certifications:
- REACH and RoHS Compliant
- California Title 24 and IECC Approved

Features

Easy Installation Options:
- Available in self-seal tubes for fast installation without adhesive, as well as standard unslit tubes, sheets, and rolls.
Environmental Stability:
- Nonpolar EPDM composition provides enhanced resistance to water, UV exposure, and mechanical damage.
Built-in Vapor Retarder:
- Reduces the need for additional vapor barriers, suitable for most conditions without supplemental barriers.
Sustainable:
- Contains no CFCs, HFCs, or formaldehyde; GREENGUARD Gold Certified for indoor air quality.
